    128X160 1.77" TFT LCD Display Module with High Contrast Ratio and 4 wire Spi Interface

    Ask Lasest Price
    Price : Negotiated
    Brand Name : oem
    Certification : ROHS
    Payment Terms : T/T, Western Union
    Supply Ability : 300k per month
    Delivery Time : 7-15 working days
    • Product Details
    • Company Profile

    128X160 1.77" TFT LCD Display Module with High Contrast Ratio and 4 wire Spi Interface

    Product Description

    LCD NameCheap small 1.77 inch color screen module 128x160 tft lcd display with ST7735

    LCD Size

    1.77 inch tft lcd display

    Resolution

    128 x3 RGB x 160 pixel

    Aspect Radio

    4:5

    Viewing Direction

    12 O'Clock

    Outline Dimension

    33.5 x45.8 x 2.3mm

    Active Area(HxV mm)

    28.03 x 35.04mm

    Contrast Ratio

    500

    Luminance(cd/m2)

    220cd/m2

    LEDS (Serial/Parallel)

    2S

    Interface

    14PIN SPI

    Backlight Supply Current/Voltage

    30mA 3.2V

    Operating Temperature

    -20~70 ℃


    * 1.77"(diagonal), 128 x3 RGB x 160 dots, 262k colors, Transmissive, TFT LCD module.
    * Viewing Direction: 12 O'Clock
    * Driving IC: ST7735/ILI9163C
    * bits data bus.
    * Logic voltage: 2.8V (typ.).
    * Without touch panel.

    * If you can't find a suitable one, contact us to get a recommendation.

    128X160 1.77" TFT LCD Display Module with High Contrast Ratio and 4 wire Spi Interface

    Packaging & Shipping

    128X160 1.77" TFT LCD Display Module with High Contrast Ratio and 4 wire Spi Interface

    Our Services

    128X160 1.77" TFT LCD Display Module with High Contrast Ratio and 4 wire Spi Interface

    1. Replacement within 30 days after the shipment of products from us due to products' problems.
    2. We can print your logo and stick your model No.on the cameras.
    3. We have long cooperation with many shipping companies and our export volume is large. The shipping companies can offer us good discounts.
    4. Professional technician supports. We have a good after-sales service team to solve your problems in time.
    5.All goods will be inspected and tested before shipment.
    6.Customer`s satisfactory is most important to us.If you have any problem or questions regarding our transaction.Please contact us by Trademanager or Email. It will be responded within 24 hours.

    Company Information
    ZhuoHong Electronic Technology has been specializing in TFT LCD display and touch screen more than 10years. There are 90% of our business is custom made display modules for projects such as industrial devices, medical and smart home applications.Our mission is to provide customer one-stop solution. With LCD display and touch screen as our product center, great trust is built with our customers.
    128X160 1.77" TFT LCD Display Module with High Contrast Ratio and 4 wire Spi Interface
    128X160 1.77" TFT LCD Display Module with High Contrast Ratio and 4 wire Spi Interface
    FAQ

    Q: When can i get the quotation?

    A: We usually quote within 12 hours after we got your inquiry.

    If it is very urgent, please call us or contact us via email, Skype or WhatsApp.


    Q: What is your warranty?

    A: We provide one year warranty.


    Q: May i buy samples from you?

    A: Yes! You are welcome to place sample order to test our superior quality and service.


    Q: How to place bulk order?

    A: 1) Tell us model number, quantity, color and other special requirements.

    2) Proforma Invoice will be made and sent to you for approval

    3) Production will be arranged once get your payment or deposit.

    4) Goods will be delivered as stated on the Proforma Invoice.


    Q: How will you deliver my goods to me?

    A: We provide as many shipping options as possible, such as DHL, UPS, FEDEX, TNT AND EMS to enable our customers get their goods rapidly at door. We also ship by economick method such as air cargo and sea cargo, direct line, air mail according to customers' request.


    Q: What about the quality of your product?

    A: We provide unrivaled quality: very rigorous testing process for incoming quality control, input process quality control, and final quanltiy control for every piece. We follow QC test procedure, and do 100% FQC to ensure your satisfication.


    Q: Can you provide OEM service?

    A: Yes! We can provide professional OEM service.


    Q: What payment method do you accept?

    A: T/T(bank transfer), L/C and paypal


    Q: Do you have any after-sales service?

    A: Yes! Our productt has professional after-sales service dept. Follow up R.M.A. Items service and upload product fireware and app for you download.

    If you have any technical questions with the goods, please feel freely to contact our technical support dept, or our sales directly.
